Continuous Glucose Monitoring System RGMS-3O

The sensor automatically generates data every 3 minutes, generating 480 data points in a single day, fully covering the two-week blood glucose fluctuation cycle, without the need for frequent equipment replacement, greatly reducing the complexity of use. The sensor adopts an efficient design, combined with the ultra-low power consumption characteristics of the transmitter, and has a battery life that exceeds ordinary products, suitable for long-term blood glucose management needs.

1: By adopting a two electrode design and combining the principle of glucose oxidase reaction, the tissue fluid glucose concentration is accurately converted into blood glucose data. Exclusive algorithms are run to optimize data accuracy, providing reliable data support for clinical diagnosis and daily management, and avoiding decision-making errors caused by data errors.

2: The electrode is thinner, causing less than 90% of the trauma compared to competitors, making it more comfortable to wear.

•

  Schematic diagram of electrodes for this product

•

  Comparison diagram between this product and competitor guide needles

The sensor has undergone aseptic treatment and is equipped with an ergonomic needle aid for painless and minimally invasive implantation. It can be worn on the upper arm; Using medical grade low sensitivity adhesive tape, breathable and hypoallergenic, comfortable and concealed to wear. The device has deep waterproof performance, and does not need to be removed for daily bathing and swimming. It can withstand the impact of daily activities, adapt to various usage scenarios, and does not affect normal life rhythms such as sleep and exercise.

Support mobile app (iOS/Android compatible), real-time synchronized data updates, intuitive display of blood glucose values, change rates, and dynamic curves.

The needle aid adopts a foolproof design and a one click operation mode, which can complete sensor implantation without professional skills and confirm successful installation within 1 minute. The interface of the mobile app is simple and intuitive, supporting custom settings for blood sugar thresholds. The device automatically vibrates and alarms when high/low blood sugar occurs, and the night warning function can effectively remind people of unexpected risks of low blood sugar, catering to the needs of different groups such as the elderly and children.

The sensor is a disposable consumable, and the transmitter and needle aid can be reused with a shelf life of 3 years, reducing the cost of use.

Product Parameters

parameter

Product Name: Continuous Glucose Monitoring System

Product specification: RGMS-3O

Target audience: ≥ 8 years old

Initialization time: 60 min

Transportation temperature: 0-40°

Storage temperature: 0-40°

Working environment temperature: 0-40°

Sensor lifespan: 15 days

Transmitter lifespan: 3 years

Sensor expiration date: 18 months

Transmitter data transmission: Bluetooth

Dimensions: Diameter 29mm, thickness ＜5.5mm

System Core Parameters

•Registration information: Produced by Huzhou Meiqi Medical Equipment Co., Ltd., with its place of origin in Huzhou, Zhejiang, China.

•Monitoring cycle: Single sensor implantation supports 15 days of continuous monitoring

•Data collection frequency: Receive raw blood glucose signals every 10 seconds, record an average blood glucose value every 3 minutes, and generate 480 data points per day.

•Measurement range: 1.7-25mmol/L

•Wireless connection: Supports Bluetooth connection.

•Data storage: The transmitter has a built-in storage module that can store complete blood glucose data for 15 days. After disconnection, the data can be automatically restored to avoid loss.

Sensor Parameters

•Design type: Disposable sterile sensor, using two electrode sensing technology

•Detection method: Implant medical grade hard probes with less than 90% trauma compared to competitors subcutaneously to monitor interstitial fluid glucose concentration.

•Working principle: Based on the principle of glucose oxidase reaction, the glucose concentration is converted into an electrical current value, which is calculated as the blood glucose value through an algorithm.

•Physical characteristics: Fixed with medical low sensitivity adhesive tape, concealed to wear, with deep waterproof performance, able to withstand daily bathing, swimming and other scenarios (IPX7 waterproof).

•Storage conditions: Store at room temperature 0-40 ° C

Transmitter Parameters

•Usage: Reusable, with a shelf life of three years

•Appearance design: Small and lightweight in size, adopting ergonomic flat design, strong concealment when worn under clothing, and high comfort.

•Connection function: Connect to a mobile app to display data.

Operation And Adaptation Parameters

•Implantation method: Equipped with an ergonomic needle aid, minimally invasive implantation can be completed with one click operation, suitable for the upper arm

•Device adaptation: Supports iOS and Android system phones

•Alarm function: Supports custom high/low blood sugar threshold and has alarm function
